适用种类 Applicable type
●CNC线切割机、雕刻机、雕铣机、高速主轴 ●CNC power generating machine, engraving machine, engraving and milling machine high speed spindle
●PCB钻孔机、铣板机 ●PCB drilling machine, milling board machine
●激光加工设备 ●laser machining machine
●服装机械、印刷机械 ●Costume machinery, prining machinery.
●注塑机械、中高频机械 ●Plastic injectine molding machine, High frequency inductor
●粉末涂装设备 ●Powder coating machine
●模具冷却 ●Mould cooling
特性与功能Features and Functions
●能精确控制机械加工温度，提高加工精度，降低成本
●无需冷却塔，节省空间
●采用防锈水循环系统
●独立式冷却机具有完整的吸送水系统，只要连接水管，就可以与设备连机工作
●Capable of precisely controlling the machining temperature so as to improve machining accuracy and reduce cost
●No need for cooling tower, save space
●Water circuiting is made of the material which can prevent from rusting
●Independent water pumping and electric control systems so that any machine can be worked together with this
●equipment only by connecting them through pipes


备注 Remark
●制冷能力是在环境温度35℃，进水温度25℃，出水温度20℃的条件下测得
●水冷机的吸水口加装过滤器
●水冷机应在通风良好，无粉尘及腐蚀性气体，四周无杂物的场所
●本机勿使用腐蚀性液体
●以上机组使用环境为5~42℃,42℃以上属高温机组，外形尺寸及相关参数会有所变更，请选型时注意
●参数表内为本公司标准机型，本公司接受客户特殊订货
●Above cooling capacity base on the ambient temperature 35℃,water inlet temperature 25℃, water outlet temperature 20℃
●Filter should be mounted on water inlet of water chiller
●Water chiller should be placed on airiness, no corrosive gas and no sundries area
●Do not use corrosive liquid
●The chillers introduced above can be used within 5~42℃, if the chillers work above 42℃, the dimension and relative paramater will be changed, please pay more attention to the specification when making a choice
●Chiller type on the above table is standard, speical order on requst
